Satellite DVB-S S2 S2X HD CI IRD
IRD3711 is a professional integrated demodulation, de-scrambler, re-mux and decoding in one case, which supports the transmission standard DVB-S2X/S2/S, ASI, TSoIP or IPTV and decode to HD-MI, CVBS, SDI, BNC, XLR interface and SPDIF.
Description
IRD3711 is a professional integrated demodulation, de-scrambler, re-mux and decoding in one case, which supports the transmission standard DVB-C, DVB-T/T2, ATSC-T, ISDB-T, DVB-S2X/S2/S, ASI, TSoIP or IPTV and decode to HD-MI, CVBS, SDI, BNC, XLR interface and SPDIF. It receives signals from satellite and gives content out through various video/audio interfaces after demodulating, de-scrambling, re-multiplexing and decoding.
The two CAMs/CIs accompanied and BISS modules can descramble the programs input from encrypted RF, ASI and IP of decoder for encrypted channels.
Its pluggable structure design greatly facilitates the change of modules (demodulator or decoder) as needed. Our professional HD integrated receiver decoder is also equipped with ASI and IP input for re-mux, and output with ASI port and IP port.
Features
Demodulator + descrambler + re-mux+ decoder modules in one box
2 *DVB-C/T/T2/S/S2/S2X/ATSC-T/ISDB-T optional Tuner input
1*ASI & 1*IP (UDP) input for re-mux
Each CAM can decrypt multiple programs from Tuner/ASI/IP
BISS descrambling (Up to 120Mbps)
4:2:0 HD/SD MPEG2, MPEG4 AVC/H.264 and HEVC/ H.265 decoding
Audio decoding: MPEG 1 Layer II, LC-AAC, HE-AAC, HE-AAC V2, Dolby Digital/Dolby Digital Plus and AC3 passthrough
Dual Stereo audio out (for SDI interface)
IP (1*MPTS & 8*SPTS) output over UDP and RTP/RTSP; 2*ASI mirrored out
CC (EIA608, EIA708) & Teletext (developing/Only for SDI) supported
Support maximum 128 PID mapping per input
Pluggable and changeable design
LCD/Keyboard and web-based NMS management
Updates via web
Applications
Digital TV broadcasting system.
Point to Point IP long distance transmission.
Lower-cost transition to IP-based services.
Multi-audio digital TV headend encoder decoder in video contribution and distribution.
Ordering Information
Model | tuner | Audio | Other function |
IRD3711A | Optional: ①DVB-C, DVB-T/T2, ISDB-T ②DVB-S/S2/S2X, ③DVB-S/S2 ④ATSC-T | One channel audio Left, Right, Stereo | Mini LED Screen for Monitoring |
IRD3711B | DVB-S/S2/S2X | Dual Stereo audio (for SDI interface) | Teletext |
