DVB-T 2 SOLUTION
DVB-T 2 is the extension of the television standard DVB-T, issued by the consortium DVB. Due to increasing scarcity of spectrum and requirements for high transmission capacity in recent years, an updated standard with more spectral efficiency is required to replace DVB-T. The DVB-T 2 system is capable of meeting these requirements, due to its increased capacity, robustness, and the ability to reuse existing reception antennas. The regions which previously adopted DVB-T sys tems, primarily countries in Europe, Africa and some countries of Asia, will be migrating to DVB-T 2.
Video acquisition | Video encoding | Video processing | Video management |
Satellite reception Signal conversion Decrypt and decode | Mpeg4/h.265 SD(Standard definition) HD(High Definition) Ultra HD | Transrating Splicing Multiplexing AD Insertion | Single point of control Third party equipment remote operations |
Modulator | Transmitter | Set Top Box | Software |
DVB-T2&IPQAM iSDB-T DVB-T/T2 DVB-S/S2 ATSC | UHF -2.7GIn/Outdoor 30W-3000WSingle/Multi-Freq Channel
| DVB-T2 DVB-T DVB-T2 Adroid STB | SMS CAS EPG Add-Value service |
Type | Item | Model name | Description |
IRD | DVB-S/S2 FTA RF tuners to IP gateway | Q1 series | l Up to 24 channels FTA tuner, 8/12/16/20 optional l Up to 512 SPTS and 4 MPTS IP OUT l Support BISS function |
8-Channel CI IRD Processor
| IRD1380 | l 8 channels RF inputs l BISS-1 and BISS-E decryption l 8×DVB-CI Slots, multi-program decryption | |
Transcoder | Mpeg-2 to H.264 Transcoder | ENC3583 | l 6 modules, up to 36 channels SD H.264 and MPEG-2 any-to-any Video Transcoding l optional MPEG-1 L2, LC AAC, AC3(optional) any to any audio transcoding, Audio streams pass-through l Multiplex supports automatic generation of SI/PSI information and manual upload l Resolution Downscale: 720*576@fps25 transcode, 720*480@fps29.97 transcode |
Encoder | H.264 Mpeg-2 SD encoder | ENC3184
| l Resolution:CIF,QVGA,QCIF(4ch) l Simultaneous encoding in MPEG-2 and H.264 formats l MPEG-1 Layer2 and AAC audio encoding l Filter Null packet Support l 8*AV Input |
H.264 /H.265 HD to IP encoder | Q7 seies | l 4 HDMI inputs per module, 6 Modules per 1RU Chassis l 2 ASI in l Up to 512 SPTS and 4 MPTS IP OUT l Advanced H.264/H.265 video compression l Audio encoding mode: MPEG-1, L2, AAC | |
Multiplexing and Scrambling
| GbE IP MPEG Processor | DCM700 | l Up to 1600Mbps GbE IP inputs, up to 800Mbps GbE IP output l Up to 4 CAS simul-cryption l Support processing for multiplexing PSI/SI Table l PID filtering,mapping and passthrough l SPTS and MPTS supported l Transrating of MPEG2/MPEG4 AVC SD and HD |
Modulator | DVB-T2 modulator | NetMode6420 | l T2MI input over ASI and IP(option) l 1 channel TS input over ASI l 10MHz reference clock input and loop out, BNC interface l 1PPS input and loop out, BNC interface |
Transmitter | Transmitter | DTT5900 -1000 | l Frequency range:470~860MHz l Output Pewer(RMS): 1000W l Supported Standard：DVB-T2, DVB-T/H,ATSC,ISDB-T/Tb l Supported Network: SFN or MFN |
CAS/SMS | CAS/SMS | SMS9000 | Windows 2003 |
2Ghz CPU,2G RAM | |||
SQL Server 2005/2008 Enterprise | |||
Up to 32 clients to control intallation |
