Multi Channel IPTV Network Device

iQ2 is a flexible encoding&modulating board combination of IPTV Network Device, this AV/HDMI/RF to RF EncoderModulators headend units are an ideal product to create your own digital TV channels over existing coax. The channel sources from any RF tuner (FTA or encrypted channels), AV and HDMI devices can be easily distributed to all your televisions quickly and efficiently, and the best quality SD/HD picture allows you to broadcast any AV/HDMI/RF device into your RF modulated channel at the lowest cost per channel.

iQ2 is an all-in-one device integrated encoding (MPEG-2/ H.264 /H.265), multiplexing and modulation functions in one standard 1 Ru case. It has total 6 module, each module can support 4 tuner or 4 AV/ HDMI input. In a word, it can convert AV/HDMI and RF signals input to RF out. It is also equipped with ASI ports to input and output, and IP port to output TS. IP output supports UDP/RTP protocol (MPTS/STPS), and supports IP outputs over RTMP/HTTP/RTSP/HLS/SRT protocol.

iQ2 is an efficient, low-cost digital TV headend device, which can be used for all kinds of digital TV transmission systems.

Features

1. Distribute FTA or encrypted Tuners, SD or HD content over RF to an unlimited number of TVs
2. flexible encoding&modulating board combination
3. Selectable DVB-S2/S2X, ISDB-T, DVB-C, DVB-T/T2, DTMB, ATSC free to air Tuners inputs
4. Optional DVB-C (QAM), DVB-T (COFDM), ATSC-T, ISDB-T, DTMB Modulation, 8/16*carrier RF out (option) (16/32*carriers DVBC QAM output optional)
5. MPEG-2 encoding supported in AV input
6. H.264/H.265 (optional) encoding supported in HDMI input
7. Two separate ASI input for External TS Multiplexing
8. DATA1:IP output over RTMP/HTTP/RTSP/HLS/SRT protocol,when RTMP/RTSP/HTTP/HLS out,H264+AAC(LC),TS bitrate is 4.5Mbps,out about 36 channels;When SRT out,H264+AAC(LC),TS bitrate is 2.5Mbps,out about 32 channels.
9. DATA2: Simulaneously 5*MPTS and 512*SPTS over UDP/RTP IP out
10. DATA3: 128 IP address inputs
11. Selectable the Value of PCR PID same as Video PID
12. LCN (Logical Channel Number) support
13. support DVB-T2 Multi PLP select
14. DVB-S2 support receive T2MI stream and PLS value setting
15. Support TTL editing
16. PSI/SI editing & inserting
17. PID Remapping & Filtering
18. Selectable LOGO,QR code,OSD insertion for every, All or Each module of local channel (encoding)
19. Support PCR correct and PCR interval adjusting
20. Easy-to-Use System Management via Web

Chart
