ENC3441/ENC3445 universal hd sd hd mpeg2 and mpeg4 Encoder

Name: ENC3441 Universal HD SD/HD MPEG-2 And MPEG-4 AVC Encoder - MPEG-2/H.264 HD Encoder - Haoxun - HAOXUN Technologies
Brand: DIBSYS
SKU: 13163

◆ CC (closed caption) (EIA708/EIA608/Line21) and GOP and PCR interval setting supported
◆ Max 1080P@ 60FPS in h.264 mode
◆ With two kinds of low latency mode,100-200MS
◆ SPTS or MPTS, and ASI output
◆ Dual power supply

Send Inquiry

specs

Description

Overview

ENC3445 has proven itself as the most advanced encoding platform for DVB-C QAM Cable, USA ATSC Off Air, DVB-T, DVB-C, DMBT, ISDB-T Clear Modulation applications available today. The hardware platform has been widely deployed for MPEG-2 and MPEG-4 AVC HD broadcasting applications with Low latency and Dolby Digital AC-3 Audio, closed captioning and redundant AC power supplies support.

ENC3445 supports the most demanding video applications. It offers codec and transport flexibility, interoperability and feature richness, and equipped with 4 channels HDMI or HD-SDI inputs and multiple codec standard (MPEG-2 and MPEG-4 AVC/H.264 video encoding and MPEG2, MPEG2-AAC, MPEG4-AAC, Dolby Digital AC3(2.0)(optional) audio encoding). It provides ultra-high quality video for your contribution workflows, IP as well as the DVB ASI output that meets MPEG-TS stream standard. The product is ideal for a broad range of applications including contribution and distribution.

Features

Superior-quality low-bitrate MPEG-2 and MPEG-4 AVC encoding of SD or HD video pre-processing technologies
Up to 4 channels SD/HD-SDI or HDMI per chassis (1-RU)
Automatic SD & HD Detection
1080p(only h.264),1080i,720p@50/60fps
MPEG2, MPEG2-AAC, MPEG4-AAC, Optional Dolby Digital AC3(2.0)(optional) audio encoding
The dialogue normalization function of AC3 encoding nicely
VCT(Virtual Channel Table) support for 8VSB ATSC and DVB-C QAM
Flexible GOP structures with B-frame and P-frame insertion in Manual of Low delay mode
Support resolution downscale conversion
18Mbps MPEG2 HD application in DVB-C and ATSC standard
Support CC (closed caption) EIA 608 & EIA 708 & Line 21 (for SDI input version only)
Simultaneous output via 4*SPTS & 1*MPTS over UDP/RTP/RTSP IP,ASI
CBR rate control
PCR correction to accurately correct several PCR of the input data
PSI/SI information creation by automatic or external
Low power consumption and high reliability with MTBF(Mean Time Between Failure) ≦87600 Hours
Easy-to-Use System Management via Web/LCD Panel
Dual Power Supply Support
