8 Chs Low Bitrate Magnum LC AAC SD Encoder

Overview

   ENC3084 is a perfect choice for broadcasters demanding the highest performance of MPEG-2 encoding SD TV for Cable, IPTV, Satellite, Terrestrial, ATSC and Hospitality Hotel TV applications. It distributes 8 Channels SD Video Signals either All in one MPTS as mirrored of DVB-ASI to Next digital TV equipment as like  Multiplexer, IPQAM or Push all SPTS Over UDP/IP to LAN IPTV Network as like software-transcoding, IPTV Streaming Server.

   ENC3084 designed to address this ever increasing demand for more video and audio services. With high density, high reliability and advanced compress arithmetic, it used for MPEG-2 4:2:0 MP@ML video and MPEG-1 Layer-II audio compression. And produce ASI and IP output data streams, and encoder decoder connected with LAN IP, widely used for Composite Analog Contribution and Distribution applications in conjunction with IRD1208 Decoders.

BUSINESS BENEFITS

◆SECAM mode of Composite analog inputs

◆Two separate DVB-ASI input built-in multiplexer from cascading to “slave” encoder to One MPTS out

◆MPEG2-TS can be fed to multiple networks simultaneously by utilizing built-in dual FE IP and DVB-ASI outputs

◆Remote and Local management -  can be managed from remote locations using web-based management, Local location using LCD/Key button

◆With high performance, 5 years warranty, widely applicable to High-end Digital TV operators, replace the world famous brand MPEG-2 Encoder, win the trust of the world's users with the highest cost-effective feature

◆Magnun chipset Technology

Features

◆8 channels composite and 8 pairs R/L analog audio per 1RU chassis

◆Advanced MPEG-2 MP@ML4:2:0 Carrier-grade video compression

◆PAL, NTSC, SECAM support

◆Simultaneous MPEG-2 TS outputs via IP, DVB-ASI

◆IP output TS is in the form of UDP packet, support MPTS/SPTS mode; when "MPTS mode" is selected for DVB mode, IP and ASI can output TS simultaneously; when “SPTS” is selected for IPTV mode, only IP can output TS, and the ASI output TS cannot be used properly

◆Switchable Multiplexing MPTS and SPTS of  Output Mode

◆Main and backup IP Ports, MPEG-TS can output In Two physical RJ45 ports simultaneously

◆Configurable Alarm parameters, Real time Monitoring the Alarm and operating temperature in running device

◆CBR & VBR rate control

◆Two separate ASI input for External TS Multiplexing

◆Audio sample rate: 32KHz, 44.1KHz, 48KHz

◆PCR correction to accurately correct

◆Precise synchronization, timing control, AV delay ≤ ± 15ms

◆Feature to adjust the audio volume prior to encoding

◆PSI/SI Information creation

◆Flexible configuration of a admin account and multiple sub accounts

◆Various video filters available to remove noise and improve the video quality

◆Low power consumption and high reliability with MTBF(Mean Time Between Failure) ≦87600 Hours

◆Forced air-cooling (left  to right side)

◆Reboot in Web-GUI

◆Management via embedded Web server,local front panel

Application

• Private and MSO Cable Systems

• Contribute Video to IP and ASI networks

• IPTV, Satellite, cable or terrestrial headend applications

• Campus, Hospitality and Education Markets
