24* HD MPEG4 AVC FULL HD Encoder

Overview



ENC3281 This unit is designed especially for high channel density Distribution Video Engineering project which support rapid deployment, OSD/Logo/QR code Insertion and compatibility Up to 24 HD-MI inputs Simultaneously. It's ideal encoder for anyone looking for an easy and affordable way to support a large number of HD channels in low cost deployment such as a Medium/Small-Scale digital Cable TV system, Hotel, Campus, Private TV station, LAN IPTV Network.



This solution is ideal for anyone looking for an easy and affordable way to support a large number of displays, such as a sports bar, house of worship, or digital signage. Multiple HD bridge units can be combined to create a headend that will support over 100 channels on your video network at each display. ENC3281 HD Encoder which is a professional HD Audio & Video encoding and multiplexing device encoder streams high-quality video and audio, and it uses the H.264 video compression standard and MPEG 1 Layer 2 audio LC-AAC, HE-AAC audio encoding format and AC3 Pass Through, and audio gain adjustment. Depending on the number of programs you have, you can very flexibly choose a different number of coding channels.



Main Features

• High density,modular 1-RU system capable of hosting up to 3 HD-MI Encoding input modules,each with 8 HD-MI channels (share the same one NMS port and DATA port )
• MPEG-4 AVC HP@L4 video compression
• Feature to adjust the audio volume prior to encoding
• Simultaneous outputs via 8* SPTS/1* MPTS over GbE IP Port(each module)
• MPEG TS/UDP and RTP/RTSP over IP output
• Support resolution downscale conversion
• Simultaneous outputs IP
• PCR de-jittering and re-stamping
• Supports SD/HD formats and frames including 1080p, 720p, 576p, 480p@25/30fps
• Selectable the Value of PCR PID same as Video PID
• Support VBR and CBR bitrate mode
• PID Remapping & Filtering & CA Filter
• Support LOGO,QR code,OSD insertion for every, All
• or Each module of local channel
• One rack unit high density, low-power consumption, stackable
• Easy-to-use web GUI
• Low power consumption and high reliability with MTBF(Mean Time Between Failure) ≦87600 Hours
• Lowest cost per HD channel, breakthrough price

Application

◆Huge Number of HD channels In limited budget

◆Migrate analog to DTV project

◆Hotel,Campus of Video engineering project

◆Convert Video to IP Connected with Camera, PC, Satellite Set Top Box, Local playout

◆Applications in Logo, OSD Insertion of Video picture

Principle Chart



Product Information

Models	Description
ENC3281A	8Chs HD-MI Input, 8*SPTS and 1*MPTS output, 1*NMS, 1*DATA
ENC3281B	16Chs HD-MI Input,16*SPTS and 2*MPTS output, 1*NMS, 1*DATA
ENC3281C	24Chs HD-MI Input, 24*SPTS or 3*MPTS output, 1*NMS, 1*DATA

ORDER INFORMATION

Product category	Product Model	Detail Description	Application
Broadcast HD Encoder	12*HD-MI FullHD Encoder ENC3240	4 HD-MI/2 ASI MUX inputs and 2ASI/1GbE RJ45 Port output per Module, Up to 3 Modules, H.264 Up to 1080p@60/59.94 / 50fps, Mpeg1 L2,SPTS/MPTS, 5Years Warranty	-Cable TV Operator -DTH, Terrestrial,Satellite Uplink -TV Studio Station
Broadcast HD Encoder	8*HD-MI  FullHD Encoder ENC3381	8 HD-MI/ASI MUX input ASI/IP out,H.264 Up To 1080p50/59.94/60fps, MPEG 1 L2/AAC 8*SPTS/1*MPTS UDP/RTP out 3Years Warranty	-Cable TV Operator -Hotel, Campus -Upgrade Analog to Digital TV -DTH, Terrestrial, Satellite Uplink
Cable TV Modulator	Carrier-grade IP QAM modulator IPQ6250	16 QAM no-adjacent/Two GbE IP per Module, 3 Modules/48QAM per 1RU, Annex A/B/C, Multiplexer/Scrambling; 5Year Warranty	-Cable TV operator -Distribute video to QAM Network
IP to RF Modulator	16/32Ch IP QAM Modulator IPM6000	2GbE port/1024 IP inputs. 16/32*QAM(Annex A/B/C, Scrambling)/8 *DVB-T /8*ATSC/6*ISDBT RF and MPTS over UDP/RTP out	-DVB/ATSC/ISDBT/DVB-T -Upgrade Analog to Digital TV -Hotel, Campus -Cable TV operator -Breakthrough Price !
DVB-S2 to RF Transmodulator	High Density Digital TV Transmodulator MSM628	16DVB-S2 FTA/2ASI/512IP Input, 16*DVB-C (Scrambling, Annex A/B ) /8 DVB-T RF/MPTS over UDP/RTP out	-Distribute video over DVB-T -Upgrade Analog to Digital TV -Hotel, Campus -Cable TV operator -Breakthrough Price !
Broadcast SD Encoder	8Chs MPEG-2/H.264 Magnun SD Encoder ENC3184	Low bitrate ; 8*AV(PAL,NTSC,SECAM)/ASI inputs; ASI/IP out; MPEG2/H.264; MPEG-1 L2/LC-AAC/ HE-AAC V1/HE-AAC	-Cable TV Operator -DTH, Terrestrial, Satellite Uplink -TV Studio Station -IPTV
